10’W x 20’L x 8’H – (House Style)



This house style product provides extra small wall clearances for maximum head room. At 10 feet wide by 20 feet long and 8 feet high, it provides space for many uses. It makes the perfect workshop or vehicle storage, but is also used for equipment and material storage and many other uses.

Unlike our competitors who require drilling or field cutting with their products, our pre-drilled frames are easily assembled with minimal hand tools. The main cover is made from long life UV resistant and fire retardant poly with fabric backing. All fabric components feature heat welded seam construction. This shelter does not come with the end panels, but they are sold separately to meet all our customers’ needs. The house style 10x20x8 is available in forest green, gray, and tan.


  • 10 oz UV Treatment Cover
  • 2 Double Zipper Doors- 9’W x 6’H
  • 6 Cable Earth Anchor Kit
  • 1-5/8 Galvanized steel Frame

SKU: N/A Category:


Exclusive Features

  • Heavy Duty Galvanized Finish on All Steel Frame Components for Maximum Strength & Long Life
  • All Pre-Drilled, Easy Bolt Together Assembly
  • Ratchet Straps for a Drum Tight Fit
  • Wind Brace Support on each Side
  • Complete Anchoring System Included
  • 10oz., CPAI-84 Polyethylene Fabric Backed Cover and Doors
  • 290 lbs. Shipped in Two (2) Boxes via Motor Freight
  • Average Install time – 2 hours
  • Easy Bolt Together Design – All Pre-drilled & Cut
  • Wind Brace Support on Both Sides
  • Two(2) Double Zipper Doors with Bottom Pockets
  • Four(4) Bungee Cord Tie Backs for Doors
  • Protective Plastic Tube End Caps – All Open Ends
  • Standard Thread Plated Hardware Kit with Retaining Nuts & Protective SS Washers
  • Quick Assembly Wrench included
  • Heavy Duty Poly Rope for Main Cover Tie Down
  • Heavy Duty Grommets on Cover & Doors
  • Two Box Shipment – easily unloaded and transported &(shown right)
  • Average Install time – 2 hours

Easy Fit Together Design – all Pre drilled & Cut

Pipe Size

Designed For Heavy Snow Load

Click here Fabric Details

One Box Shipment – Easily unloaded and transported

Product Packaging Details

permanent anchors

Click here for Steel Tubing Details

Standard Specifications

  • Nominal Size 10’ Wide x 20’ Long x 8’ High
  • Arches Six(6) on 48” Spacing 1 5/8” Frame Members
  • Standard End Door Size10’ Wide  X 6′ High at edge double zipper door each end
  • Available Colors & Exterior Colors: Green or Gray
    All Interiors: Bright White Only
  • Shipping Weight 290 lbs shipped in Two(2) boxes Shipped via Motor Freight
  • Pallet Dimensions
  • 40″ x 68″ x 15″
  • Box Dimensions
  • Box 1: 63.5″ Long x 17.5″ Wide x 7.5″ High
  • Box 2: 66.5″ Long x 20.5″ Wide x 8.75″ High
  • Main Cover
  • UV Protected Fabric Backed Poly Material 10 0z. Weight. 24 Mil. thick.
  • Fire Retardant Standard
  • Main Cover & Doors meet CPAI -84 Section 5
  • Anchors
  • Six(6) 36” Anchors with U-Bolts & Drive Rod Std.
  • Stock Number
  • 12x20x08- GA102008HGN, GA102008HGY

Product Documentation

  • the product spec sheet
  • the assembly manual

Additional information

Weight 290 lbs
Dimensions 20 × 10 × 8 in

Tan, Gray
