14’W x 42’L x 17’H – (Peak Style)

$3,999.00 $3,439.00



The 14x42x17 portable shelter is perfect for both residential and commercial use. This industrial shelter provides additional space to store your large boats, RVs, and vehicles. It can be used to house commercial equipment, provide outdoor protection at commercial job sites, and as a portable building for your temporary or long-term needs.

The roll-up door kit is included for the front door. The structure comes with 2 double zipper doors to allow easy access with drive-thru capabilities. As with all our structures, the galvanized steel frame offers durability and sustainability for long-term use. Get the superior protection you need to give you peace of mind for your most important investments.



Included

  • 10 oz. UV Treatment Cover
  • 2 Double Zipper Doors-12’W x 12’8″H (9’3″W at top)
  • 22 Cable Earth Anchor Kit
  • 2-3/8″ Galvanized Steel Frame
  • Roll Up Door Kit for front door included
Clear

SKU: N/A Category:

Description

Exclusive Features

  • Heavy Duty Galvanized Finish on All Steel Frame Components for Maximum Strength & Long Life.
  • Easy Bolt Together Design –All Pre-drilled & Cut
  • Wind Brace Support on Both Sides
  • Two(2) Double Zipper Doors with Bottom Pockets
  • One (1) complete Roll-up Door Kit
  • Protective Plastic Tube End Caps – All Open Ends
  • Standard Thread Plated Hardware Kit with Retaining Nuts & Protective SS Washers
  • Quick Assembly Wrench included
  • Heavy Duty Poly Rope for Main Cover Tie Down
  • Heavy Duty Grommets on Cover & Doors
  • Twenty-Two (22) permanent anchors included
  • Twelve(12) Box Shipment
  • Average install time – 8 to 10 hours

Pipe Size

Click Here for Fabric Details



Click Here for Steel Tubing Details



Standard Specifications

  • Nominal Size 14’ Wide x 42’ Long x 17’ High
  • Arches Eleven (11) on 48” Spacing 2-3/8” diameter frame members
  • Standard End Door Size12’ Wide x 11’8″ High at edge double zipper door each end
  • Available ColorsOuter Colors: Green and Gray
    All Interiors: White Only
  • Shipping Weight1350 lbs shipped in Twelve(12) boxes Shipped via Motor Freight
  • Pallet Dimensions
  • 44″ x 86″ x 43″
  • Box Dimensions
  • Box 1: 70″ Long x 20″ Wide x 8″ High
  • Box 2: 70″ Long x 20″ Wide x 8″ High
  • Box 3: 57″ Long x 13″ Wide x 6″ High
  • Box 4: 70″ Long x 21″ Wide x 8″ High
  • Box 5: 68″ Long x 21″ Wide x 8″ High
  • Box 6: 57″ Long x 13″ Wide x 7″ High
  • Box 7: 58″ Long x 14″ Wide x 7″ High
  • Box 8: 52″ Long x 11″ Wide x 8″ High
  • Box 9: 53″ Long x 10″ Wide x 6″ High
  • Box 10: 53″ Long x 9″ Wide x 6″ High
  • Box 11: 71″ Long x 17″ Wide x 8″ High
  • Box 12: 87″ Long x 27″ Wide x 8″ High
  • Main Cover
  • UV Protected Fabric Backed Poly Material 10 0z. Weight. 22 Mil. Thick.
  • Fire Retardant Standard
  • Main Cover & Doors meet CPAI -84 Section 5
  • Anchors
  • Twenty-Two (22) 36” Anchor with U-Bolts & Drive Rod Std.
  • Stock Number
  • 14x42x15-PB144217HGN, PB144217HGY

Product Documentation

  • the product spec sheet
  • the assembly manual

Additional information

Dimensions 42 × 14 × 15 cm
Color :

Green, Grey
