22’W X 24’L X 12’H – (Animal Run-In)

$2,499.00



The Rhino Shelters House-style Run In shelter is designed to provide protection for livestock, while not sacrificing ventilation. The house-style roof prevents any water logging or snow build-up. Assembling a Rhino Shelter requires minimal effort and tools. The frame of the shed is designed in a specific manner, so that no cutting or drilling is required.

The fabric for the main cover is CPAI-84 rated and manufactured using fire retardant, UV resistant poly, featuring woven backing and heat-welded seams. The outer and inner layers sandwich a special layer in between called Inner Black Scrim. This layer has a coating that prevents any sunlight from infiltrating the material.

Please Note: End Panels Are Not Included With Livestock Shelters & Sold Separately.

Included

  • 10 oz. UV Treatment Cover
  • 6 Earth Anchor Kit
  • 2- 3/8″ Galvanized Steel Frame

SKU: N/A Category:

Description

Exclusive Features

  • Heavy Duty Galvanized Finish on All Steel Frame Components for Maximum Strength & Long Life
  • All Pre-Drilled, Easy Bolt Together Assembly
  • Wind Brace Support on all 4 corners
  • 10oz., CPAI-84 Polyethylene Fabric Backed Cover
  • Protective Plastic Tube End Caps – All Open Ends
  • Standard Thread Plated Hardware Kit with Retaining Nuts & Protective SS Washers
  • Quick Assembly Wrench
  • Heavy Duty Poly Rope for Main Cover Tie Down
  • Heavy Duty Grommets on Cover
  • Average Install time – 2 hours
  • Shipping Weight 789 lbs. shipped in Six (6) boxes Shipped via Motor Freight

Pipe Size

Designed For Heavy Snow Load

Click here Fabric Details

permanent anchors

Click here for Steel Tubing Details

Standard Specifications

  • Product Size 22′ Width x 24′ Length x 12′ Height
  • Arches Seven (7) on 48″ spacing: 2-3/8″ galvanized frame members
  • Available Colors Forest Green, Gray and Tan
    Interior Color White
  • Anchors Fourteen (14) 36″ Anchors with U-Bolts & 36″ Drive Rod
  • Shipping Method Shipped via Motor Freight Only
  • Box Dimensions Box 1: 60″ Long x 15″ Wide x 5″ High
  • Box 2: 88″ Long x 11″ Wide x 5″ High
  • Box 3: 50″ Long x 18″ Wide x 10″ High
  • Box 4: 65″ Long x 26″ Wide x 9″ High
  • Box 5: 60″ Long x 15″ Wide x 5″ High
  • Box 6: 67″ Long x 23″ Wide x 9″ High
  • Main Cover Fire Retardant Standard Main Cover meets CPAI -84 Section 5
  • UV Protected 24 mm, fabric-backed polyethylene, 10 oz weight
  • Shipping Weight 789 lbs. shipped in six (6) boxes
  • SKU LV222412HGN, LV222412HGY, LV222412HTN

Product Documentation

  • Manual 22W x 24L x 12H House

Additional information

Weight 789 lbs
Dimensions 24 × 22 × 12 in
Color :

Gray, Green, Tan
